鉚合機器

本頁的機器為鉚合機器,是鉚合我們的金屬製品;例如:四合釦、押釦、塑鋼釦、五爪釦、空心釘、撞釘、雞眼、中空釘等,而鉚合機器大致分為手動型、半自動型、全自動型三種效能。例如:26LD、130LD、132LD為手動型,完全用手將鉚合物置入模具上;而202L、202C、202E、105L則為將單一鉚合物自動送料至模具,是為半自動型;另202A則是產能效率較高的機器,如四合釦最常用此類型,因為它可以很快將面釦+母釦(或公釦+底釦)鉚合在物料上,屬全自動型。每個人的鉚合產品不盡相同,所需求程度也不同,我們會在與客人實際了解溝通後,建議並提供最好的選項。

  • 202L Table Type Machinery For Mini Eyelet
    Throat Depth 5"
    Stroke 32 mm
    Power 1/4 HP
    N.W. 100 kgs
    G.W. 170 kgs
    Packing Dimension 109x79x163 cm
  • 202C Table Type Machinery For Eyelet or Snap Fastener
    Throat Depth 5"
    Stroke 50 mm
    Power 1/4 HP
    N.W. 100 kgs
    G.W. 170 kgs
    Packing Dimension 80x80x164 cm
  • 202A Auto Type Machinery For Eyelet or Snap Fastener
    Throat Depth 5"
    Stroke 50 mm
    Power 1/4 HP
    N.W. 180 kgs
    G.W. 260 kgs
    Packing Dimension 73x67x164 cm
  • 202E Stand Type Machinery For Eyelet or Snap Fastener
    Throat Depth 5"
    Stroke 50 mm
    Power 1/4 HP
    N.W. 100 kgs
    G.W. 170 kgs
    Packing Dimension 86x79x163 cm
  • 105L Large Riveting Machinery
    Tube Length 38-50 mm 25-38 mm
    Throat Depth 250 mm 250 mm
    Tube Dlameter 3-5 mm 4-7 mm
    Stroke 65-90 mm 65-90 mm
    Power 1/2 HP 1/2 HP
    N.W. 290 kgs 335 kgs
    G.W. 350 kgs 400 kgs
    Packing Dimension 95x103x186 cm 102x76x173 cm
  • 130LD Simple and Multi-function Riveting Machinery
    N.W. 55 kgs
    G.W. 58 kgs
    Packing Dimension 58x50x120 cm



  • 132LD Simple and Multi-function Riveting Machinery

    It can be 铆釘系列various types of 铆釘系列and button. Only change the mold that can be use.



    N.W. 31 kgs
    G.W. 36 kgs
    Packing Dimension 58x50x120 cm



  • 26LD Simple and Multi-function Riveting Machinery
    It can be 铆釘系列various types of 铆釘系列and button. Only change the mold that can be use.

    Carton Q'ty 4 pcs
    N.W. 23 kgs
    G.W. 24 kgs
    MEA'MT 0.6 CU. FT.
